| Brand Name: | Hsinda |
| Model Number: | RAL |
| MOQ: | 100KG |
| Price: | Negotiable |
| Supply Ability: | 50000TONS/YEAR |
Fast Curing Crystal White Electrostatic Powder Coating Polyester TGIC Free for Architecture
What is Powder Coating?
The powder coating process uses a solvent free dry mix of plastic resins, pigments and fillers that melt and fuse together when heated. The solid particles of coating are electrostatically charged in a spray gun and carried by low velocity air to the surface of the piece to be coated. The electrostatic charge holds the powder particles in place while the part is cured in an oven. The heat of the oven causes a chemical reaction to occur and the powder to cure, creating a highly durable finish.
Powder coating is an environmentally friendly process unlike solvent based wet paint systems. With EPA regulations growing ever stricter, powder coating is fast becoming the technology of choice. Since the powder coating process does not use solvents in any way, VOC emission problems are eliminated.
Powder Coatings resist cracking and peeling and are extremely abrasion corrosion and chemical resistant, but is not a rust inhibitor. The performance characteristics of powder coating match or exceed the characteristics achieved from conventional solvent based coatings.
Powder coatings are available in a large variety of stock colours, metallics, textures and special effects. Made to Order colours require a lead time of 6 days and have a minimum quantity of 100 kgs.
Any ferrous or non-ferrous object that can hold an electrostatic charge and withstand the heat of the curing process can be powder coated. Powder can be applied to intricate surfaces and still maintain a uniform finish across the entire piece. Powder coating is ideal for items such as:
Product tests
| Test Item | Test Method | Test Result |
| Film Thickness | ISO2360 | 60-80um |
| Pencil Hardness | ASTMD 3363 | HB-H |
| Bending | ISO1519 | ≤10mm |
| Grid Test 1mm | ISO2409 | 0 Class |
| Impulse Test | ASTMD2794 | Pass |
| Cupping Test | ISO1520 | ≥8mm |
| Heat Resistance 1000 hours | ISO6270-1 | Popping<1mm |
| Salt Spray 1000 hours | ISO9227 | Corrosion Spreading<1mm |
| Trade Terms | FOB, CIF, CRF, CNF |
| Payment Terms | T/T, L/C, West Union, PayPal etc. |
| Delivery time | 3-7 days after payment |
| Packaging |
Big Size: 39*26*43 (unit:cm) Weight: N.W. 25kg G.W. 26kg Small Size:39*26*37 (unit:cm) Weight: N.W. 20kg G.W. 21kg |
| Pallet | If customer required, we could provide pallet, package size: 213*120*120 (unit:cm) |
| about Container | 20' container loads nealy 15tons; 40' container loads nearly 23tons |
| Shipping |
By sea, by air, by courier Sample Powder will be delivery by courier ,like DHL,UPS,FedEx etc. 3-8 DAYS to arrival Official Order Powder will be ship by SEA .15-30 DAYS to arrival |
A WEATHER RESISTANT POWDER COATING FOR EXTERIOR OR INTERIOR APPLICATIONS
CURE SCHEDULE 400F/10 MIN.
70-95% GLOSS @ 60 DEGREES
RECOMMENDED MIL THICKNESS – 2.0-3.0 MILS
SPECIFIC GRAVITY – 1.48
THEORETICAL COVERAGE @ R.M.T. – 130 FT2
SALT SPRAY RESULTS – 1,500 HOURS +
